Amprobe HD160C Heavy-Duty Digital Multimeter with True-RMS
Description
The Amprobe HD160C Digital Multimeter with True-RMS is designed for professional use in harsh environments. The meter is unusually rugged and reliable in everyday heavy use applications. The meter is made using waterproof construction to prevent dirt, grime and moisture from entering the case and causing inaccurate readings or damaging shorts. Built of tough, fire-retardant thermoplastic resistant to grease and chemical spills, with all sensitive components shock-mounted for a drop resistance to at least eight feet. Model HD160C has an extended voltage measurement capability of 1500 Vdc and 1000 Vac, unmatched by any other line of digital multimeters. The extended voltage ranges can withstand transients up to 12 kV.
Features
- Highest voltage capability, measuring to 1500 Vdc and 1000 Vac.
- CAT IV 1000 V rated.
- Special sealing for environment and water resistance. IP67 rated.
- Constructed with drop-resistant housing and PCB mounting.
- Measures capacitance, temperature and frequency.
- Superior 10,000 count resolution with bar graph.
- Magne-Grip™ holster, frees both hands for work.
- Includes high voltage test leads with threaded alligator clips.
- Temperature measurement built-in.
- Frequency and capacitance.
- Digi-Glo™ bright backlight.
- Display 4 digit LCD, 9999 counts, with annunciators, menu features and 41-segment bargraph.
- Input overload indication OL, -OL.
- Automatic polarity indication.
- Auto Power-Down
- Wide choice of Amprobe multimeter accessories
| Specifications |
|
DC Volts Ranges |
1000 mV, 10 V, 100 V, 1500 V |
|
DC Volts Resolution |
0.1 mV in 1000 mV range |
|
DC Volts Accuracy |
± (0.1% of reading + 5 digits) |
|
DC Volts Input Impedance |
10 MΩ |
|
DC Volts CMRR |
> 120 dB up to 1500 Vdc |
|
DC Volts NMRR |
> 60 dB at 50 or 60 Hz |
|
DC Volts OL Protection |
1500 Vdc or 1000 Vac RMS |
|
DC Volts Transient Protection |
12 kV impulse (1.2 μs/50 μs) based on EN 61010-1:2001 impulse requirement for at CAT IV 1000 V/1500 Vdc product. This product should not be used in installations where transients exceed 12 kV. |
|
DC Current Ranges |
100 μA, 1000 μA, 10mA, 100mA, 400mA, 2A (Auto/Manual ranging) |
|
DC Current Resolution |
0.01μA in 100 μA range. |
|
DC Current Accuracy |
100 μA range ± (0.5% of reading + 10 digits) |
|
DC Current Input Protection |
2A/1500V fast blow ceramic fuse, 8×65 mm on A input, FP700 |
|
AC Volts True RMS Ranges |
1000 mV, 10 V, 100 V, 1000 V |
|
AC Volts True RMS Resolution |
0.1 mV in 1000 mV range |
|
AC Volts True RMS Accuracy |
1000 mV (45 Hz to 400 Hz): ± (1.2 % of reading + 10 digits) |
|
AC Volts True RMS Input Impedance |
10 MΩ |
|
AC Volts True RMS Conversion Type |
True RMS, ac coupled 5 % to 100 % of range |
|
AC Volts True RMS Crest Factor |
≤ 3 |
|
AC Volts True RMS OL Protection |
1500 V dc or 1000 V ac RMS |
|
Resistance Rages |
200 Ω, 2 kΩ, 20 kΩ, 200 kΩ, 2 MΩ, 20 MΩ |
|
Diode Test |
1.0 mA, 3 Vdc |
|
Temperature Measurement |
-20°C to 1300°C (-4°F to 2372°F) |
|
Continuity Test |
Audible sound at <50 Ω ± 25 Ω, 100 ms |
|
Transient Protection |
12 kV impulse (1.2 μs/50 μs) based on EN 61010-1:2001 impulse requirement for at CAT IV 1000V product. This product should not be used in installations where transients exceed 12 kV. |
|
Battery Life |
150 hours, alkaline |
|
Dimensions |
200 x 102 x 59 mm (7.9" x 4.0" x 2.3") |
|
Weight |
642 g (22 oz) with battery |
|
Safety |
Meets EN 61010-1 CAT IV 1000 V (1500 V DC max) Class II, EN 60529:IP67 |
|
