Model CI-200 Touch Screen Current Interrupter with GPS by Cath-Tech

SKU#: 04-29519
GPS Sync. for Interruption. 200 amp Capacity for AC or DC
$3,864.00

  • Features

    • DC capability 200A DC at up to 200V DC.
    • AC capability 200A AC at up to 440V AC.
    • 4 x 20 character LCD display.
    • Rugged case with storage for cables, AC adapter and antenna.
    • 16-key pad for local programming.
    • Global Positioning System (GPS synchronization for interruption precision of better than 1 millisecond.
    • Microprocessor driven.
    • 5-program capability.
    • Programmable interruption cycle.
    • Programmable start and stop times.
    • Programmable start and stop day and month.
    • Holds power ON when not interrupting.
    • Color-coded output terminals.
    • RS-232 communication port.
    • Flash memory (never forgets program).

    Synchronization

    • Global Positioning System (GPS) synchronization for 1 microsecond accuracy.
    • Displays time and date as well as latitude and longitude.
    • Displays number of program running.

    Programmability

    • 5-program capability.
    • Programmable interruption cycle (ON and OFF time).
    • Programmable start and stop times (24-hour clock).
    • Programmable start and stop day and month.
    • Holds power ON when not interrupting.
    • Utilizes UTC 24-hour clock.
    • Communicates using Windows HyperTerminal.

    CI-200/GPS Kit Includes:

    • CI-200/GPS Interrupter
    • AC adapter, 120/240V.
    • Power cables with safety connectors
    • Magnet-mount GPS antenna
    • Operator manual




  • Technical Specifications

    Case
    Dimensions
    Weight
    Battery
    Battery Charger
    Power
    GPS Engine
    GPS Antenna
    Display
    Keypad
    Com Port
    Output Terminals
    Power Cables

    Plastic (orange)
    430 X 340 X 170 mm
    10 Kg
    7.2 Volt, 2 Amp Hour NMH
    120/240V internal charger
    ON/OFF Switch
    Trimble low-power engine
    Magnet-mount, 3M cable
    4-line by 16 characters per line LCD
    16-key tactile membrane
    9-Pin Male D RS-232
    Supercon
    Neoprene-insulated, with Supercon connector, copper alligator clip and vinyl boot.
