Cathodic Test Boxes by Bingham & Taylor

Cast iron rim and lid, ABS plastic body.

  • 2-1/2" Shaft Cathodic Protection Test Boxes

    P225 SR Series P202CNG TEST

    Catalog Number Shaft Size ID Lid Size OD Approx Wt. Lbs.
    P225 SR Series 2-1/2" 3" 2
    P202CNG TEST 2-1/2" 3-1/2" 2

    Features & Options
    • Plastic rim with cast iron lids, ABS plastic body.
    • Test readings available without removing lid.
    • Pre-wired test stations with varying wire gauges, colors, lengths.
    • Lids available in drop turn locking and mechanical locking designs.
    • Telescoping test stations with separate top and bottom sections.
    • Custom lettering on lid available.
    • Available with or without flared or squared base to prevent pull-out or settling.
    • Length of box as desired by customer.
    • Terminals can also be secured in place beneath lid.

    2-1/2" Shaft Cathodic Protection Test Boxes

    P200NFG TEST P200 TEST

    Catalog Number Shaft Size ID Lid Size OD Approx Wt. Lbs.
    P200 TEST 2-1/2" 4" 3
    P202NFG TEST 2-1/2" 3-1/4" 3

    Features & Options
    • Cast iron rim and lid, ABS plastic body.
    • Lids available in drop turn locking and mechanical locking designs.
    • Terminal blocks available in varying designs with multiple terminals.
    • Telescoping test stations with separate top and bottom sections.
    • Length of box as desired by customer.
    • Available with or without flared or squared base to prevent pull-out or settling.
    • Custom lettering on lid available.
    • These boxes can also be utilized as a tracer-wire or locating box.

  • 3" Shaft Cathodic Protection Test Boxes

    P306 TEST P334DT TEST

    Catalog Number Shaft Size ID Lid Size OD Approx Wt. Lbs.
    P334DT TEST 3" 4-1/2" 7
    P306 TEST 3" 5-3/4" 11

    Features & Options
    • Cast iron rim and lid, ABS plastic body.
    • Lids available in drop turn locking and mechanical locking designs.
    • Terminal blocks available in varying designs with multiple terminals.
    • Telescoping test stations with separate top and bottom sections.
    • Available with or without flared or squared base to prevent pull-out or settling.
    • Length of box as desired by customer.
    • Custom lettering on lid available.

  • 4" Shaft Cathodic Protection Test Boxes

    P445DT TEST E.T.C. TEST

    Catalog Number Shaft Size ID Lid Size OD Approx Wt. Lbs.
    P445DT TEST 4" 4-3/4" 5
    E.T.C. TEST 4" 5-1/2" 7

    Features & Options
    • Cast iron rim and lid, ABS plastic body.
    • Lids available in drop turn locking and mechanical locking designs.
    • Terminal blocks available in varying designs with multiple terminals.
    • Telescoping test stations with separate top and bottom sections.
    • Available with or without flared or squared base to prevent pull-out or settling.
    • Custom lettering on lid available.
    • Length of box as desired by customer.

    4" Shaft Cathodic Protection Test Boxes

    P475SQ TEST P465 TEST

    Catalog Number Shaft Size ID Lid Size OD Approx Wt. Lbs.
    P475SQ TEST 4" 4-3/4" 13
    P465 TEST 4" 4-1/2" 14

    Features & Options
    • Cast iron rim and lid, ABS plastic body.
    • Drop in lid designs only.
    • Custom lettering on lid available.
    • Terminal blocks available in varying designs with multiple terminals.
    • Telescoping test stations with separate top and bottom sections.
    • Length of box as desired by customer.
    • Available with or without flared or squared base to prevent pull-out or settling.
    • Paving risers available for P465 TEST Box 3/4" - 2"

  • 5" Shaft Cathodic Protection Test Boxes

    P525RD  TEST P525SQ TEST EQ-5 TEST

    Catalog Number Shaft Size ID Lid Size OD Approx Wt. Lbs.
    P525RD  TEST 5-1/4" 7-1/2" 26
    P525SQ TEST 5-1/4" 6" Sq. 23
    EQ-5 TEST 5-1/4" 6" 23

    Features & Options
    • Cast iron rim and lid, ABS plastic body.
    • Drop in lid designs only.
    • Custom lettering on lid available.
    • Terminal blocks available in varying designs with multiple terminals.
    • Telescoping test stations with separate top and bottom sections.
    • Length of box as desired by customer.
    • Available with or without flared or squared base to prevent pull-out or settling.
    • Paving risers available for P525 RD TEST and EQ-5 TEST
