Densyl Tape, Corrosion Protection for Pipes, Flanges & Valves, by Denso

SKU#: Denso Densyl Tape, Corrosion Protection for Pipes
Provides long-term corrosion protection for pipes, flanges and valves.

Grouped product items

  • Description

    Description

    Densyl Tape is composed of a non-woven synthetic fabric carrier, fully impregnated with a neutral petrolatum compound with inert fillers and corrosion inhibitors.

    Uses

    Densyl tapes are designed to withstand extreme temperature variations. The tapes provide long term corrosion protection to pipes, flanges, valves and related surfaces.

    Features

    • Applied to marginally prepared surfaces (SSPC SP 2-3)
    • Conforms to irregular shapes and profiles
    • Can be applied to cold, wet surfaces
    • Not effected by water, acid, salts or soil organics
    • Encapsulation of lead paint
    • Contains no solvents
    • Easy application from arctic to tropical temperatures
    • Ready for immediate service after application
    • Meets AWWA C217 Standard
    • Over a sixty-five year history of proven applications

    Application

    Prepare surfaces by removing all loose scale, rust or other foreign matter in accordance to SSPC SP2 "Hand Tool Cleaning" or SP3 "Power Tool Cleaning". High pressure water wash of 3,000 - 7,000 psi is also suitable. Apply a thin film of Denso Paste, which serves as a primer. Spirally wrap the tape with a minimum 1'' overlap. For severely corrosive environments, a 55% overlap is recommended. While wrapping, press air pockets out and smooth all lap seams. For additional mechanical protection, an overwrap may be used to increase impact strength and electrical resistance.

    Irregular surfaces such as valves, flanges, etc. may require the use of Densyl Mastic or Denso Profiling Mastic. Refer to the product sheets for these specific products for information on application and selection.


  • Specifications

    Properties English Metric

    Thickness  (ASTM D1000)
    Weight
    Breaking strength (ASTM E96 - 66 Proc A)
    Elongation at break
    Breakdown voltage (55% overlap)
    Resistance to cathodic disbonding
       (ASTM G-8 30 days)
    Resistance to acids, alkalies, salts
    Temperature range
    Roll length

    46 mils
    0.295 lbs/ft2
    0.006 perms avg.
    10% avg.
    16 kV min
    0.28 in2 avg.

    Excellent
    -22°F to 158°F
    33 ft min

    1.15 mm
    1.44 kg/m2
    0.006 perms avg.
    10% avg.
    16 kV min
    180 mm2 avg.

    Excellent
    -30°C to 70°C
    10 meters min

    Recommended primer

    Denso Paste, Denso Paste S105,
    or Denso Priming Solution

  • Quantity Estimates

    Tape WidthRolls / CaseCoverage with
    1" Overlap
    Coverage with
    55% Overlap
    2"
    4"
    6"
    8"
    12"
    36
    18
    12
    8
    6
    87 ft2/case
    145 ft2/case
    162 ft2/case
    150 ft2/case
    177 ft2/case
    87 ft2/case
    87 ft2/case
    87 ft2/case
    77 ft2/case
    87 ft2/case
