Integra "Premium" Polycarbonate Enclosure with Locking Latch
Description
Integra enclosures are injection-molded, non-metalic, engineered thermoplastics, designed to provide the best combinations of strength, durability, design features, and aesthetics.
| 6X6X4 | Mechanical and Thermal | Flammable/UV Ratings |
 |
Instrumented Dart Impact @ 73°F, 565 in-lb. Falling Ball Impact @ 73° 900 in/lb. Test Spec. UL-746 Deflection Temperature @264 psi, 270 Deg. F, Test Spec. ASTM D648 Modulus of Elasticity 340 ksi, Test Spec. ASTM D790 Temperature Range, -40 to 265 Deg. F |
Flame Rating – UL, 5VA. Test Spec. UL-94 Outdoor UV Exposure, F1. Test Spec UL |
|
3rd Party Approvals: UL-50/c-UL Listed (files#E229365, #E207562) |
||
| 8X6X4 | Mechanical and Thermal | Flammable/UV Ratings |
 |
Instrumented Dart Impact @ 73°F, 565 in-lb. Falling Ball Impact @ 73° 900 in/lb. Test Spec. UL-746 Deflection Temperature @264 psi, 270 Deg. F, Test Spec. ASTM D648 Modulus of Elasticity 340 ksi, Test Spec. ASTM D790 Temperature Range, -40 to 265 Deg. F |
Flame Rating – UL, 5VA. Test Spec. UL-94 Outdoor UV Exposure, F1. Test Spec UL |
|
3rd Party Approvals: UL-50/c-UL Listed (files#E229365, #E207562) |
||
| 8X8X4 | Mechanical and Thermal | Flammable/UV Ratings |
 |
Instrumented Dart Impact = 565 in-lb. (Tested at 73°F)
Falling Ball Impact = 900 in/lb. (Test Spec. UL-746, at 73°F)
Deflection Temperature = @264 psi (Test Spec. ASTM D648 270°F)
Modulus of Elasticity = 340 ksi (Test Spec. ASTM D790)
Temperature Range = -40 to 265 °F
|
Flame Rating = UL, 5VA. (Test Spec. UL-94)
Outdoor UV Exposure = F1. (Test Spec UL)
|
|
3rd Party Approvals: UL-50/c-UL Type 4X Listed (file #E207562) IP 66
|
||
| 10X8X2 | Mechanical and Thermal | Flammable/UV Ratings |
 |
Instrumented Dart Impact @ 73°F, 565 in-lb. Falling Ball Impact @ 73° 900 in/lb. Test Spec. UL-746 Deflection Temperature @264 psi, 270 Deg. F, Test Spec. ASTM D648 Modulus of Elasticity 340 ksi, Test Spec. ASTM D790 Temperature Range, -40 to 265 Deg. F |
Flame Rating – UL, 5VA. Test Spec. UL-94 Outdoor UV Exposure, F1. Test Spec UL |
|
3rd Party Approvals: UL-50/c-UL Listed (files#E229365, #E207562) |
||
| 10X8X4 | Mechanical and Thermal | Flammable/UV Ratings |
 |
Instrumented Dart Impact @ 73°F, 565 in-lb. Falling Ball Impact @ 73° 900 in/lb. Test Spec. UL-746 Deflection Temperature @264 psi, 270 Deg. F, Test Spec. ASTM D648 Modulus of Elasticity 340 ksi, Test Spec. ASTM D790 Temperature Range, -40 to 265 Deg. F |
Flame Rating – UL, 5VA. Test Spec. UL-94 Outdoor UV Exposure, F1. Test Spec UL |
|
3rd Party Approvals: UL-50/c-UL Listed (files#E229365, #E207562) |
||
| 10X8X6 | Mechanical and Thermal | Flammable/UV Ratings |
 |
Instrumented Dart Impact = 565 in-lb. (Tested at 73°F)
Falling Ball Impact = 900 in/lb. (Test Spec. UL-746, at 73°F)
Deflection Temperature = @264 psi (Test Spec. ASTM D648 270°F)
Modulus of Elasticity = 340 ksi (Test Spec. ASTM D790)
Temperature Range = -40 to 265 °F
|
Flame Rating = UL, 5VA. (Test Spec. UL-94)
Outdoor UV Exposure = F1. (Test Spec UL) |
|
3rd Party Approvals: UL-50/c-UL Type 4X Listed (file #E207562) IP 66 |
||
| 12X10X4 | Mechanical and Thermal | Flammable/UV Ratings |
 |
Instrumented Dart Impact = 565 in-lb. (Tested at 73°F)
Falling Ball Impact = 900 in/lb. (Test Spec. UL-746, at 73°F)
Deflection Temperature = @264 psi (Test Spec. ASTM D648 270°F)
Modulus of Elasticity = 340 ksi (Test Spec. ASTM D790)
Temperature Range = -40 to 265 °F
|
Flame Rating = UL, 5VA. (Test Spec. UL-94)
Outdoor UV Exposure = F1. (Test Spec UL)
|
|
3rd Party Approvals: UL-50/c-UL Type 4X Listed (file #E207562) IP 66 |
||
| 12X10X6 | Mechanical and Thermal | Flammable/UV Ratings |
 |
Instrumented Dart Impact = 565 in-lb. (Tested at 73°F)
Falling Ball Impact = 900 in/lb. (Test Spec. UL-746, at 73°F)
Deflection Temperature = @264 psi (Test Spec. ASTM D648 270°F)
Modulus of Elasticity = 340 ksi (Test Spec. ASTM D790)
Temperature Range = -40 to 265 °F
|
Flame Rating = UL, 5VA. (Test Spec. UL-94)
Outdoor UV Exposure = F1. (Test Spec UL)
|
|
3rd Party Approvals: UL-50/c-UL Type 4X Listed (file #E207562) IP 66 |
||
| 14X12X6 | Mechanical and Thermal | Flammable/UV Ratings |
 |
Instrumented Dart Impact = 565 in-lb. (Tested at 73°F)
Falling Ball Impact = 900 in/lb. (Test Spec. UL-746, at 73°F)
Deflection Temperature = @264 psi (Test Spec. ASTM D648 270°F)
Modulus of Elasticity = 340 ksi (Test Spec. ASTM D790)
Temperature Range = -40 to 265 °F
|
Flame Rating = UL, 5VA. (Test Spec. UL-94)
Outdoor UV Exposure = F1. (Test Spec UL)
|
|
3rd Party Approvals: UL-50/c-UL Type 4X Listed (file #E207562) IP 66 |
||
| 16X14X7 | Mechanical and Thermal | Flammable/UV Ratings |
 |
Instrumented Dart Impact = 565 in-lb. (Tested at 73°F)
Falling Ball Impact = 900 in/lb. (Test Spec. UL-746, at 73°F)
Deflection Temperature = @264 psi (Test Spec. ASTM D648 270°F)
Modulus of Elasticity = 340 ksi (Test Spec. ASTM D790)
Temperature Range = -40 to 265 °F
|
Flame Rating = UL, 5VA. (Test Spec. UL-94)
Outdoor UV Exposure = F1. (Test Spec UL)
|
|
3rd Party Approvals: UL-50/c-UL Type 4X Listed (file #E207562) IP 66 |
||
| 18X16X10 | Mechanical and Thermal | Flammable/UV Ratings |
 |
Mechanical and Thermal
Instrumented Dart Impact @ 73°F, 565 in-lb.
Falling Ball Impact @ 73° 900 in/lb. Test Spec. UL-746
Deflection Temperature @264 psi, 270 Deg. F, Test Spec. ASTM D648
Modulus of Elasticity 340 ksi, Test Spec. ASTM D790
Temperature Range, -40 to 265 Deg. F
|
Flammable/UV Ratings Flame Rating – UL, 5VA. Test Spec. UL-94
Outdoor UV Exposure, F1. Test Spec UL
|
|
3rd Party Approvals: UL-50/c-UL Listed (files#E229365, #E207562) |
||
