Model CI-50TS Touch Screen Current Interrupter with GPS by Cath-Tech

Includes Touch Screen User Interface
$2,195.00
SKU
CI-50TS

Features

Portable current interrupter

  • GPS continuously synchronized
  • Touch screen user interface
  • Not polarity or orientation sensitive
  • Programmable local time GPS offset
  • Battery conserving sleep mode
  • Start with OFF or ON
  • 5 programmable time schedules
    • Interruption cycle
    • Start and stop times
    • Start and stop dates
  • Holds CP power ON or OFF when not interrupting
  • SuperCon® output terminals
  • Storage compartment for cables and accessories
  • Comprehensive 2 year warranty

Included

  • CI-50TS Current Interrupter
  • AC power adapter; 120/240V AC, 50/60Hz input
  • Interruption cables with copper alligator clamps and rubber boots
  • Magnet mount GPS antenna
  • Operation manual

Technical Specifications

  • Capacity : Up to 50A, 150VDC, 100VAC RMS
  • Switching: Bidirectional electronic relays
  • Case: IP67 / NEMA 4X plastic case with O-ring seal and locking hasp
  • Dimensions: 27cm wide, 20cm high, 25cm deep (11” x 8” x 10”) • Weight: 4.6 kg (10 lb)
  • Battery: 11.1V 6 Ahr Lithium Ion
  • User Interface: 4.3” color LCD capacitive touch screen
  • External Power: Accepts 12-30V AC/DC external power to supplement battery life •
  • GPS synchronized, with magnet mount antenna for easy placement with view of the sky
    • Cycle time 1 second to 360 seconds
    • Off time: 0- to 9999mSec (synchronized to the beginning of the minute, 0 seconds)
  • Non GPS synchronized operation also possible
