Fill-Coat #6 Pipeline Casing Fill by Trenton

A cold-installed / high temperature casing filler that can be installed at ambient temperature as low as 50°F (10°C) with portable pumps.

  • Description

    Fill-Coat #6 Pipeline Casing Filler is a cold-installed/high temperature petroleum based casing filler compound that can be installed at ambient temperature as low as 50°F (10°C) with portable pumps. The product is used in bridge abutment casings, and it can be used in casings with elevated temperatures.

    Fill-Coat #6 is used to fill the annulus of gas distribution bridge abutment casings. It prevents corrosion by filling the void in the casing annulus. In addition, new water is prevented from entering the gas-filled casing. Applications include aboveground cased pipe (like bridge abutment casings).




  • Advantages

    • Non-Melting
    • Heavier than water
    • Anti-Corrosiv
    • Water Resistant
    • Dielectric
    • Inert
    • Non-Toxic
    • Non-Flammable
    • Pliable


  • Application Procedure

    Fill-Coat #6 can be installed by a variety of portable air powered mastic pumps (1, 5, or 50 gallon capacity). The material is pumped into the annulus of the casing until the casing is full. The casing ends can be sealed with Trenton Fill-Putty, Trenton #2 Wax-Tape or an epoxy filler once it is full.




  • Specifications

    Flash Point
    Specific Gravity
    Temperature Range
    Color
    Consistency
    Dielectric Strength
    Density

    ASTM D 92 greater than 300°F
    1.02 to 1.08
    30°F to 225°F
    Dark brown
    Grease-like
    Greater than 100 Volts per mil
    ASTM D1475 7.898 lbs per gallon
