TC Color Coat by Tapecoat

The Multi-Environmental All Purpose Wax Coating System

  • Description

    Color Coat is a versatile 60 mil environmentally friendly wax coating system designed to protect piping and metal structures from damage and deterioration caused by corrosion. The specially formulated odorless, selfhardening, wax coating system is suited for both above and below grade application.

    Color Coat is a highly conformable coating that can be applied over most stable surfaces whether they are dry, damp or wet. A coating ideal for protecting structures such as bridge crossings, riser pipe, flanges, valves and all types of piping and metal structures. Especially suited for vaults and close quarter applications because it is virtually odorless, fume free and non toxic

    Resistant to Ultra Violet Light and environmental exposure, Color Coat is durable and aesthetically pleasing, available in a wide variety of colors including a full range of Safety Code colors.

  • Application

    Primer: Apply TC COLOR COAT PRIMER by hand (glove) or mechanical means, to a minimum thickness of 2 to 4 mils.

    Tape: Apply Color Coat Wrap using either the spiral or cigarette method. A 50% overlap is preferred, though a minimum overlap 1” or 20 per cent of the tape width, which ever is greater is acceptable when conditions allow. Hand smooth and seal overlaps.



    Surface Preparation

    Surface should be clean. Remove all loose or non-bonded material, rust scale, dirt, burrs, and sharp edges. Remove excess moisture whenever practical.

    REFERENCE: Steel Structures Painting Council (SSPC)

    SP-2 Hand Tool Cleaning
    SP-3 Power Tool Cleaning

    Swedish Standard(St,Sa)

    St 2 Hand Tool Cleaning
    St 3 Power Tool Cleaning


    Composition

    The Color Coat coating system consists of a fully impregnated fiber carrier saturated with a specially formulated blend of waxes and plasticizers that make up this versatile, nontoxic, environmentally safe, easily to apply, protective coating for use in the widest range of coating application needs.



    Coating Overwrap (option)

    T/R RUGGED WRAP – for additional abrasion resistance. Fiberglass reinforced outerwrap, UV Resistant, Water Activated, comes in many colors. Hand applied with gloves.

  • Technical Data

    Desciption
    Color A Veriety Available
    Wax Tape Non Toxic Blend
    Thickness 60 mil
    Bonding System Wax Encapsulation
    U V Resistance Excellent
    Environment Above or Below Grade
    Wet or Dry Substrate
    Max Operating Temp 140ËšF ( 60°C)
    Leachable Chlorides None



  • Case Packaging

    Coating Material: 50 square Feet per Case
    Case Weight: 15 LBS

    Roll Size Rolls Per Case
    2” X 12.5’ 24
    4” X 25’ 6
    6” X 25’ 4
